PVC & PET Heat Shrink Tube
PET Heat Shrinkable Tube
Green, biodegradable, comply with all the EU environmental standards, structure: Flat look
Powered by Froala Editor
FEATURES
• High impact
• High toughness
• Structure: flat type
Powered by Froala Editor
TYPICAL APPLICATIONS
Material data: PET
Continuous operating temperature: -40˚C~125˚C
Minimum shrink temperature: 60˚C
Minimum fully recovery temperature: 125˚C
Standard color: Black, transparent (Other colors can be customized)
Powered by Froala Editor
TECHNICAL DATA
| Property | Test method | Unit | Performance |
| Bend (280mm) | - | mm | UnderΦ8<3.0 aboveΦ10<3.5 |
| Density | ASTM D792 | kg/L | 1.3-1.4 |
| Tensile Strength | ASTM D638 | N/m2 | 5.0x107-10.0x107 |
| Break elongation | ASTM D638 | % | 200~300 |
| Lead column strength | - | N/mm | 100~200 |
| Water absorption | ASTM D570 | % | <2.0% |
| Dielectric strength | ASTM D149 | KV/mm | >80 |
| Surface resistivity | ASTM D257 | Ω | >109 |
| Volume resistivity | ASTM D257 | Ω.cm | >1014 |
Powered by Froala Editor
DIMENSIONS
| Part no. | Size(mm) | Diameter(mm) | Thickness(mm) | Transverse shrinkage(%) | Longitudinal shrinkage(%) | Standard Packing(m/roll) |
| SPET-0037 | 3.7 | 6.5±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0040 | 4.0 | 7.1±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0045 | 4.5 | 8.0±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0050 | 5.0 | 9.0±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0060 | 6.0 | 10.6±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0063 | 6.3 | 10.9±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0070 | 7.0 | 12.5±0.1 | 0.08±0.01 | 49±4 | 12±4 | 200 |
| SPET-0080 | 8.0 | 13.9±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0090 | 9.0 | 15.5±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0100 | 10.0 | 17.1±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0112 | 11.2 | 19.0±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0120 | 12.0 | 20.3±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0125 | 12.5 | 20.2±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0130 | 13.0 | 21.9±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0135 | 13.5 | 22.6±0.1 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0140 | 14.0 | 23.3±0.2 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0148 | 14.8 | 24.8±0.2 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0160 | 16.0 | 26.8±0.2 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0180 | 18.0 | 29.9±0.2 | 0.10±0.02 | 49±4 | 12±4 | 200 |
| SPET-0190 | 19.0 | 31.5±0.2 | 0.105±0.02 | 49±4 | 12±4 | 200 |
| SPET-0200 | 20.0 | 32.9±0.2 | 0.105±0.02 | 49±4 | 12±4 | 200 |
| SPET-0220 | 22.0 | 36.3±0.2 | 0.105±0.02 | 49±4 | 12±4 | 200 |
| SPET-0250 | 25.0 | 41.1±0.2 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-0254 | 25.4 | 42.0±0.2 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-0300 | 30.0 | 49.2±0.2 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-035 | 35.0 | 56.6±0.2 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-0400 | 40.0 | 62.5±0.3 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-0420 | 42.0 | 68.4±0.3 | 0.105±0.02 | 49±4 | 12±4 | 100 |
| SPET-0430 | 43.0 | 72.5±0.3 | 0.105±0.02 | 49±4 | 12±4 | 100 |
